Wheelbase (mm)
|
3335 / 4240 / 5100
|
Torque (Nm)
|
315nm@1400-1600 RPM / 400nm@1600 RPM
|
Engine
|
BS III / BSIV / BSVI (available)
|
Power (KW )
|
75KW@2600 RPM / 85KW @2600 RPM (Option available)
|
Clutch
|
Single Plate Dry Diaphragm Type
|
Gear Box
|
Synchromesh Manual 5 Forward and 1 Rear
|
No. of tyres
|
6+1
|
Tyre Size (inch)
|
7.50 X 16 - 16PR / 8.25 x 16- 16PR (Option avaialble)
|
Front & Rear Suspension
|
Progressive Suspension
|
Shock Absorber
|
Available
|
Min. Ground Clearence (mm)
|
208 / 228
|
Model
|
S7 School /Staff Bus and S7 School Bus N /Staff Bus N
|
No. Of Seats
|
WB 3335: 30+D(3x2) & 25+D+CD(2x2), WB4240: 42+D(3x2) & 31+D+CD (2x2) & 33+D+CD(2x2), WB 5100: 52+D(3x2), 39+D+CD (2x2)available
|
Type of Seats
|
Standard School Type Seats (3X2)
|
No. of seats (semi reclining pushbacks)
|
N/A
|
No. of seats (High Back seats)
|
WB 4240:30+D(2x2) , WB 5100 : 37+D+CD (2x2)
|
No. of seats (School seats)
|
WB 3335: 30+D(3x2) & 25+D+CD(2x2), WB4240: 42+D(3x2) & 31+D+CD (2x2) & 33+D+CD(2x2), WB 5100: 52+D(3x2), 39+D+CD (2x2)available
|
Steering
|
Power Steering
|
A/C
|
Optional
|
Telematics
|
N/A
|
Adjustable Driver Seat
|
Yes
|
Tiltable Steering
|
Yes
|
Brakes
|
Hydraulic / Air Brake (optional)
|
Parking Brakes
|
optional
|
Anti Roll bar
|
optional
|
ABS
|
ABS/NON ABS (Optional
|
Battery
|
12V
|
Fuel Tank Capacity (Litres)
|
90Ltrs/ 180 Ltr. (optional)
|
Engine and Transmission
|
4 - Cylinder In - line Common Rail Direct Injection Diesel Turbo-charger with Inter-cooler
|
Vehicle and Differential
|
N/A
|
Bus body
|
Fully Built Up / Chassis available
|
