Wheelbase (mm)
|
3335 / 4240/ 3940/4760
|
Torque (Nm)
|
315 Nm @ 1600 ± 200 RPM/400 NM @ 1500 ± 100 rpm
|
Engine
|
BSIII/BSIV/BSVI
|
Power (KW )
|
75 KW @ 2600 rpm (optional) / 85 KW @ 2800 rpm
|
Clutch
|
Dry Single Plate Diaphragm type
|
Gear Box
|
Synchromesh Manual 6 Forward and 1 Rear / Synchromesh Manual 5 Forward and 1 Rear (optional)
|
No. of tyres
|
6+1
|
Tyre Size (inch)
|
7.50 X 16 16 PR / 8.25 X 16 PR
|
Front & Rear Suspension
|
Semi Elliptical with Multi leaf Springs
|
Shock Absorber
|
Available
|
Min. Ground Clearence (mm)
|
210 mm
|
Model
|
SuperAB School Bus / SuperAB XT School Bus and SuperAB School Bus N / SuperAB XT School Bus N
|
No. Of Seats
|
WB 3335: 32 + D (3x2) & 25+D+CD (2x2) , WB 4240 : 41+D (3x2) , 31+D+CD(2x2), 33+D+CD(2x2) Option available - WB 3940:29+D+CD(2x2) & 31+D+CD (2x2) and WB 4760 : 37+D+CD (2x2)
|
Type of Seats
|
3 X 2 & 2x2
|
No. of seats (semi reclining pushbacks)
|
N/A
|
No. of seats (High Back seats)
|
N/A
|
No. of seats (School seats)
|
WB 3335: 32 + D (3x2) & 25+D+CD (2x2) , WB 4240 : 41+D (3x2) , 31+D+CD(2x2), 33+D+CD(2x2) option available
|
Steering
|
Power Steering
|
A/C
|
Optional
|
Telematics
|
N/A
|
Adjustable Driver Seat
|
Yes
|
Tiltable Steering
|
Yes
|
Brakes
|
Air Brakes
|
Parking Brakes
|
optional
|
Anti Roll bar
|
optional
|
ABS
|
ABS/NON ABS (Optional)
|
Battery
|
12V
|
Fuel Tank Capacity (Litres)
|
90 ltrs. / 180Ltr (optional)
|
Engine and Transmission
|
4 - Cylinder In - line Common Rail Direct Injection Diesel Turbo-charger with Inter-cooler
|
Vehicle and Differential
|
N/A
|
Bus body
|
Fully Built Up / Chassis available
|
